Ateis IDA8S User Manual

IDA8 Global-Net User Manual520
© 2020, ATEÏS. All rights reserved.
DC Input
18V~26V, Typical 24V
120mA
-
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 100Hz ~ 18kHz
Front Panel Loudspeaker
Impedance:
4Ohm
Maximum Power:
@ 1kHz = 1W
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 200Hz ~ 8kHz
Mechanical
Dimensions( W x L x H):
105mm x 190mm x 50mm
Cable Length:
100m(control and power on the same cable)
900m(when power line connects to junction box).
Weight:
4.7 kg (10.4 lbs)
Color:
RAL7035
Operating temperature:
0ºC ~ 55ºC
Comes standard with PPM JB junction box and CAT5 cable (1.5m)
9.5.5 PSS-AS
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
250mA
-
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 100Hz ~ 18kHz
Noise Gate Threshold:
-84dBu ~ -24dBu
Max Output Level:
-54dBu ~ 35dBu
Attack Time:
8ms
Release Time:
100ms
Front Panel Loudspeaker
Impedance:
4Ohm
Maximum Power:
@ 1kHz = 1W
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 200Hz ~ 12kHz
Mechanical
Dimensions( W x L x H):
250mm x 140mm x 75mm
Touch Screen:
Diagonal: 5"/Resolution = 800 x 480
Weight:
1.1Kg
Maximum Cable Length:
100m on CAT5 cable
Operating temperature:
0ºC ~ 55ºC
