IDA8 Global-Net User Manual40
© 2020, ATEÏS. All rights reserved.
This connector supplies a 24VDC source.
24V DC Input:
Main 24VDC power supply connector.
AC Power Socket:
Main 110~240 V 1.2A, 47~63Hz AC power input with fuse. If 24V DC and AC power are input
at the same time, IDA8C will use AC power, and switch to DC power if there is no AC power
input.
Fuse Rating: 1.6A
3.1.2.3 Peripherals
The following table list the peripherals supported by IDA8SAB.
Remote console with paging ability.
Remote console for Paging and Event Triggering(Element
Control, Master/Sub Preset Control).
Remote console for Master/Sub Preset Controlling and
Element Controlling.
Evacuation Input extension.
Evacuation Input & output extension
Auto noise gain for audio signals
Wall mounted cabinet remote paging console with 8 buttons/
zones.
Wall mounted cabinet remote paging console with 16 buttons/
zones.
Wall mounted cabinet remote paging console with touch
screen and Fireman Microphone.
Wall mounted cabinet remote paging console with telephone
styled microphone.
Wall mounted cabinet remote paging console with 24 buttons/
zones and 2 extra selectable microphone sources.
A grouped console is comprised of a pad with a monitoring
speaker, a pad with a gooseneck and 8 buttons/zones, and
two pads with 8 buttons/zones.
A remote dialer for making telephone calls via IDA8's
telephone hardware.
An RF transceiver to communication between DialPad and
IDA8, DialPad can work without a physical connection.
Max. Number: The max. number of peripherals through per PDC port by using a Junction Box. For
example: On the PDC port, you can connect 32 PPM AS through junction boxes and are able to
assign IDs in sequence for each unit in Ateis Studio.
Eth. Limit: The maximum number of IP that can be assigned over the network.
3.1.2.4 3rd Party Control
The following table lists the 3rd Party Control protocols supported by IDA8SAB.
Read/Write value of parameters.
Stepped adjustment for parameters.
