DSP Components 345
© 2020, ATEÏS. All rights reserved.
Distance: Specify the distance to compute the delay time of a channel.
Application
Take a conference application as an
example, attendants sit at the back row will
receive the sound from the speakers with
time difference (delay) due to the distance
between the speakers.
The solution is to add a delay to the
speakers placed in the middle of the room.
6.2 Dynamic
6.2.1 AGC/AGC Stereo
With this Automatic Gain Control(AGC), the input signal can be increased or decreased to a target
level. You can adjust the gain source automatically by setting a target level. There are two types of
AGC, one is the signal channel, and the other is stereo.
Control Window
Release: If the release button is on, the [Release Time] setting will be activated.
Bypass: Disable the AGC Function(i.e. Bypasses the audio signal from input to output).
Active LED: The LED will flash when the gain is controlled.
Threshold: Set the threshold level and the audio level is above, then the gain will be controlled.
Don't set the threshold too low, otherwise it will hear unexpected sounds such as ambient noise.
Target Level: Determine which relative volume you want to target.
Max Gain: Determine the maximum of automatic gain.
