Ateis IDA8S User Manual

Technical Data 521
© 2020, ATEÏS. All rights reserved.
9.5.6 URC-150/URC-150 AS
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
24VDC
20mA
-
Mechanical
Dimensions( W x L x H):
84mm x 33mm x 84mm
Weight:
0.08KG (0.17 lbs)
Maximum Cable Length:
100m on CAT5 cable
Operating temperature:
0ºC ~ 55ºC
9.5.7 URC-200/URC-200 AS
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
50mA
-
Mechanical
Dimensions( W x L x H):
140mm x 108mm x 34mm
Weight:
0.35Kg (0.7 lbs)
Screen:
Diagonal = 2" /Resolution = 176 x 220
Color:
RAL7016
Maximum Cable Length:
100m on CAT5 cable
Operating temperature:
0ºC ~ 55ºC
9.5.8 PPM-IT5
Electrical
Item
Voltage
Current Consumption
Connect Type
PoE
44~57VDC
250mA
RJ45
24VDC
18~30VDC
-
DC Jack
MAX Power consumption: 6W
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 100Hz ~ 18kHz
Noise Gate Threshold:
-84dBu ~ -24dBu
Max Output Level:
-54dBu ~ 35dBu
Attack Time:
8ms
Release Time:
100ms
Front Panel Loudspeaker
Impedance:
4Ohm
Maximum Power:
@ 1kHz = 1W
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 200Hz ~ 12kHz
Mechanical
Dimensions( W x L x H):
250mm x 140mm x 80mm
Touch Screen:
Diagonal: 5"/Resolution = 800 x 480
Weight:
1.1Kg
Color:
RAL7016
Maximum Cable Length:
100m on CAT5 cable
Operating temperature:
0ºC ~ 55ºC
