IDA8 Global-Net User Manual424
© 2020, ATEÏS. All rights reserved.
6.20.5 Duplex Output
For AES/EBU output, the duplex output modules represent the physical outputs accessible on the
rear panel of the device. There are several separate modules for use with each of the audio boards.
Element Description
Overload: The channel level above the chosen
Overload Threshold.
Volume: The meter shows the channel level.
Mute: Mute/unmute the output channel, the LED
lights in red while the channel is muted.
Signal: Indicate if a channel is activated or not.
Level: The level of signal output of the module.
Overload thd.: Set the threshold of the overload
indicator.
6.21 Page Control
6.21.1 S/W Page Control
Allow to activate and route the audio inputs to the outputs.
This is not a mixer, only one input can be routed to an output.
