IDA8 Global-Net User Manual72
© 2020, ATEÏS. All rights reserved.
Name: The name of PPM AS object.
RS485 Target: Indicate the connector on audio
processor that PPM AS connected in the
design window.
Talk Mode: Specify the behavior of key pressing
for paging. There are two modes:
Push: Push and hold the key for paging
request, release the key to end paging.
Lock: First push for paging request, if request is
grant then start paging, push again to end
paging.
Key Count: Specify how many keys in PPM
AS.
Pre/Post-Announcement:
o Enable: Tick/Untick the checkbox to
enable/disable the pre/post-announcement
chime playing.
o Name: Display the name of the message.
Enable: Tick/Untick the checkbox to enable/
disable the post-announcement chime playing.
3.2.1.1.4.1 Settings
Double click the PPM AS object to open the window of PPM AS Settings.
Name: The name of PPM AS.
Talk Announcement: The settings window of announcement message.
o Pre/Post-position: Enable or disable pre/post-announcement chime playing. Click the [...] to
select the internal message file which stored in the audio processor.
The name of chime can not be more than 16 characters (including the characters of file
