3.2.1.3 PPM-IT5 IP-Based Touchscreen Paging Console
The PPM-IT5 IP-based paging console allows call-paging and messages broadcasting. Its back-lit
touch screen is designed for user-friendly operating. The 3 hardware keys can be freely assigned by
software. All paging parameters are programmable: zones assigned to different buttons, name
zones, group zones, messages triggering or event control. A total of 168 keys over 14 pages allow
zone selections. The prerecorded messages and chime are stored in PPM-IT5 IP paging console.
Thanks to the echo cancellation, the PPM-IT5 delivers full duplex crystal clear sound quality.
Features
5” TFT LCD color touch panel.
Full duplex intercom, zone paging, and control.
High quality gooseneck microphone.
Loudspeaker built-in.
Ethernet interface including PoE (Power Over Ethernet).
24 VDC external power supply (if no PoE available).
AGC(Automatic Gain Control) function.
Noise Reduction and Acoustic Echo Cancellation.
G.711/G.722/G.726/G.727/G.729/MP3 audio encoding/decoding and AAC+ decider.
SNMP (Simple Network Management Protocol).
Full duplex audio.
Memory for message recording and playback.
POWER/FAULT EVAC LEDs.
RJ 9 for optional telephone headset, 3.5mm socket for Earphone-Mic headset.
2 mini-jack plugs for optional headsets.
