System Products 55
© 2020, ATEÏS. All rights reserved.
Make sure the wattage unit of each group must be in the same power capacity. See the
picture above, the EVAC and Backup channel shall be put together in one group with the
same watt (1000W). The Voice and Music channel shall be put together in the second group
with the same watt (200 W).
3.1.5.3.3 Backup Sharing Mode
Backup Sharing Mode
The master unit IDA8C (Switch Mode) is connected to IDA8SAB-SW slave units by Ateis Local-
Net with full power back-up.
The 9 amplifier channels are supplied for each zone individually, and one backup amplifier
channel will act as backup for the 9 amplifiers once they break down.
