Ateis IDA8S User Manual

Technical Data 501
© 2020, ATEÏS. All rights reserved.
Mechanical
Dimensions(W x H x D):
436mm (W) x 88mm (H) x 300mm (L)
Weight:
5Kg
Colour:
RAL7016
Operating Temperature:
0°C ~ 40°C
9.1.4 IDA8S
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~30V, Typical 24V
2A
-
DC Output
18V~30V, Typical 24V
0.5A
-
AC Maximum Consumption: 48W
Amplifier Zone Outputs
Maximum level: 14 dB
Output Impedance: 50 Ohm
Bandwidth: ±1dB@ 20Hz ~ 20kHz
THD+N (Total Harmonic Distortion plus Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
0.04
%
20~20kHz@+4dBu
-12dBu
-
0.06
%
20~20kHz@-2dBu
-24dBu
-
0.06
%
20~20kHz@-14dBu
-40dBu
-
0.06
%
20~20kHz@-30dBu
-54dBu
-
0.06
%
20~20kHz@-44dBu
EIN (Equivalent Input Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
-81
dBu
20~20kHz@150Ω
-12dBu
-
-93
dBu
20~20kHz@150Ω
-24dBu
-
-104
dBu
20~20kHz@150Ω
-40dBu
-
-112
dBu
20~20kHz@150Ω
-54dBu
-
-115
dBu
20~20kHz@150Ω
Speaker Line/Amplifier
Speaker Line/Amplifier
Maximum Power: 700W(RMS)
Maximum Power (Siren + Message): 1000W
Configurable Audio Output
Maximum level = 14 dBu
Output Impedance = 50 Ohm
Bandwidth =±1dB@ 20Hz ~ 20kHz
THD+N (Total Harmonic Distortion plus Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
0.04
%
20~20kHz@+4dBu
-12dBu
-
0.06
%
20~20kHz@-2dBu
-24dBu
-
0.06
%
20~20kHz@-14dBu
-40dBu
-
0.06
%
20~20kHz@-30dBu
-54dBu
-
0.06
%
20~20kHz@-44dBu

Ateis IDA8S Specifications

General

Brand	Ateis
Model	IDA8S
Category	Security System
Language	English
