Ateis IDA8S User Manual

DSP Components 405
© 2020, ATEÏS. All rights reserved.
6.13.26 Pulse Generator
6.13.26.1 Control
The Pulse Generator Control component is a component which gives pulse. Note: The connected
input pin is a high active pin and gives pulse when deactivating.
Control Window
Elements
High Time(sec)/Lo Time(sec): The Hi time and
Lo time of output pulse.
6.13.26.2 Trigger
The Pulse Generator Control component is a component which gives pulse, and can also set the
number of pulse time. Note: The connected input pin will be triggered and give pulse when it's in
raising edge.
