IDA8 Global-Net User Manual422
© 2020, ATEÏS. All rights reserved.
6.20.2 Monitor Output
The monitor output modules represent the amplifier zone output accessible on the rear panel of the
device. There are 2 separate modules for use with the zone boards 1 and 2.
Control Window
Element Description
Overload: The channel level above the chosen
Overload Threshold.
Volume: The meter shows the channel level.
Mute: Mute/unmute the output channel, the LED
lights in red while the channel is muted.
Signal: Indicate if a channel is activated or not.
Level: The level of signal output of the module.
Overload thd.: Set the threshold of the overload
indicator.
6.20.3 Mono Output
For AES/EBU output, the mono output modules represent the physical outputs accessible on the
rear panel of the device. There are several separate modules for use with each of the audio boards.
