Ateis IDA8S User Manual

System Products 79
© 2020, ATEÏS. All rights reserved.
Monitoring loudspeaker
5” full color touch-screen, 800 x 480 pixels
14-pages x 12 keys
Power, status and fault indicator
Status information access from the touch screen panel
EN54-16 certified
3.2.1.2.1 Control Panel
Microphone:
A 280mm flex microphone.
Power LED:
This LED lights up when the PSS-AS is powered on.
Fault LED:
To display fault status of system. Following table lists the states of fault:
Status
Frequency
Activity
Permanent
There are faults in audio processor.
Blinking
° °
Lost communication with audio processor.
EVAC LED:
Light up when system is under evacuation paging.
Status
Frequency
Activity
Permanent
System is under evacuation paging.
Touch Screen:
A back-lit touch screen with 5" diagonal and 800 x 480 resolution contains 14 pages, 12 keys for
each pages can freely config to paging or adjustment parameters in audio processor.
Left Button:
Press to increase the volume of built-in speaker.
Middle Button:
Press to decrease the volume of built-in speaker.
Right Button:

Ateis IDA8S Specifications

General

Brand	Ateis
Model	IDA8S
Category	Security System
Language	English
