9 Technical Data
9.1 Processor
9.1.1 IDA8C
Electrical
Item
Voltage
Current Consumption
Comment
AC Input
115V~230V
1.6A@100V,
0.7A@240V
Frequency:50Hz~60Hz
DC Input
18V~30V, Typical 24V
2A
-
DC Output
18V~30V, Typical 24V
0.5A
-
AC Maximum Consumption: 48W
Amplifier Zone Outputs
Maximum level: 14 dB
Output Impedance: 50 Ohm
Bandwidth: ±1dB@ 20Hz ~ 20kHz
THD+N (Total Harmonic Distortion plus Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
0.04
%
20~20kHz@+4dBu
-12dBu
-
0.06
%
20~20kHz@-2dBu
-24dBu
-
0.06
%
20~20kHz@-14dBu
-40dBu
-
0.06
%
20~20kHz@-30dBu
-54dBu
-
0.06
%
20~20kHz@-44dBu
EIN (Equivalent Input Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
-81
dBu
20~20kHz@150Ω
-12dBu
-
-93
dBu
20~20kHz@150Ω
-24dBu
-
-104
dBu
20~20kHz@150Ω
-40dBu
-
-112
dBu
20~20kHz@150Ω
-54dBu
-
-115
dBu
20~20kHz@150Ω
Configurable Audio Output
Maximum level = 14 dB
Output Impedance = 50 Ohm
Bandwidth =±1dB@ 20Hz ~ 20kHz
THD+N (Total Harmonic Distortion plus Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
0.04
%
20~20kHz@+4dBu
-12dBu
-
0.06
%
20~20kHz@-2dBu
-24dBu
-
0.06
%
20~20kHz@-14dBu
-40dBu
-
0.06
%
20~20kHz@-30dBu
-54dBu
-
0.06
%
20~20kHz@-44dBu
EIN (Equivalent Input Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
-81
dBu
20~20kHz@150Ω
-12dBu
-
-93
dBu
20~20kHz@150Ω
-24dBu
-
-104
dBu
20~20kHz@150Ω
-40dBu
-
-112
dBu
20~20kHz@150Ω
-54dBu
-
-115
dBu
20~20kHz@150Ω
