Normal AMP input from RU-MAIN to SPA:
o RU-MAIN: AMP Inputs For Zone1~8.
o SPA: Balanced Input.
Backup AMP input from IDA8C to RU-MAIN:
o IDA8C: Backup AMP1 (AMP I).
o RU-MAIN: AMP Inputs For Backup AMP1 (P_BKP1+S_BKP1).
Backup AMP input from RU-MAIN to SPA.
o RU-MAIN: AMP Inputs For Backup AMP1 (BKP1).
o SPA: Balanced Input.
3.3.7.5.2 Switch Mode
Full & Partial Redundancy
Normal AMP input from IDA8C-SW to RU-MAIN:
o IDA8C-SW: AMP Input EVAC, Backup, Voice, Music.
o RU-MAIN: AMP Inputs For Zone1~8 (P_ZONE, S_ZONE).
Normal AMP input from RU-MAIN to SPA:
o RU-MAIN: AMP Inputs For Zone1~4.
o SPA: Balanced Input.
