Connector of line A speaker.
Connector of line B speaker.
Connector of 100V audio coming from amplifier.
The IDA8 output is exactly the same audio signal to line A and B. Two speakers can connect to
one zone for redundancy purposes, one connects to line A, another connects to line B. Both
speaker lines are monitored, meaning if damage to a speaker is detected, a global fault "Line A/
B Error" will be generated.
Backup Amplifier I/Os:
Two backup amplifier connectors include 0 dB to amplifiers and 100V return from amplifiers.
Amplifier Zone Outputs:
8 Zone 0dB output to amplifiers.
Bypass Mode Outputs:
This port is used to share the bypass mode microphone signals through the IDA8C-IDA8S
network (only needed when using a fiber optic network).
PDC (Peripherals Device Controller) Connectors:
Two RJ-45 connectors are used to connect consoles or peripheral devices. For example, PSS
AS, URC-150AS, PPM AS connect to the IDA8SAB via this connector.
Local Ateis Net Connectors:
Optional card to build a local dedicated IDA8C-IDA8S network.
Configurable Audio I/Os:
Two configurable 0dB audio I/O port A and B. Each port is available to assemble an audio card.
There are 4 channels on each audio I/O card.
Telephone Line Input:
A connector for a telephone signal coming from telephone company (optional).
Interface: a/b (analog), support 74 countries.
Dialing modes: vocal
Connection: PABX
Supported Standards: FSK and DTMF
Interface: RJ11
Technology: Noise Suppression, Line Echo Cancellation, Voice Enhance
Telephone Connector:
A connector for external telephone connection (optional).
Contact Outputs:
8 logic output channels to close/open circuit for an external device. This contact is normally
open.
Evacuation Inputs:
9 evacuation contact inputs that allow the monitoring of external contact. They also can be used
in UGA mode and are triggered by a voltage polarization change.
24V DC Output:
