System Overview 21
© 2020, ATEÏS. All rights reserved.
Now 'Drag N Drop' the device/system into the
configuration window.
The [Set Audio Module] window will appear,
click [Create] button to continue.
Then a IDA8C block will be created.
12. Add a Tone component and connect it to the Output component.
Double click the IDA8C icon to open the
[IDA8C DSP Configuration - IDA8C1], allowing
to edit the DSP configuration. The following
example shows how to use the Tone Generator
and the Output component.
13. Compile and Store
Once the design is done, click [Compile All]
icon, then the Compiling window will be
appeared afterwards.
