IDA8 Global-Net User Manual280
© 2020, ATEÏS. All rights reserved.
Picture Setting/Skin Setting:
1. Picture Setting: Select the custom figure files.
Caption/File Size: The name/size of figure file.
: Click to select the file users intend to store into the device. Note: By selecting all the
files one at a time, click the first button at the first row [All].
: Click to open a quick-access of [Resource Manager] window, a database contains
files that can be used in a device configuration.
Save : Click Save button to store the adjustment and upload your configuration
into the device.
2. Skin Setting: Select a skin file.
Please send all the bmp files to your Ateis dealer, we will generate a skin file for you.
Then you can put this skin file into the source path, see the picture as below.
Size: 144 x 80
[ ]: Click to select the skin folder. See the picture below,
To Next Page
