IDA8 Global-Net User Manual316
© 2020, ATEÏS. All rights reserved.
A check box used to enable or disable the monitor function. If users have this function
disable, the [Bypass Monitoring] LED will light up.
Enable Leakage:
A check box used to enable or disable the leakage detect function.
Leakage Threshold (1k ohm):
A threshold value for the leakage detection. If the leakage impedance is lower than this
value, the leakage circuit will be detected and show fault report.
Enable Leakage Open Relay:
Enable the function of leakage open relay.
Leakage Open Threshold (1k ohm):
If the leakage impedance is lower than this value, the fault Leakage replay will be detected
and opened relay, this will result in no audio sound and show fault report.
Leakage Calibration:
If the system detects a leakage fault, but the problem wasn't found in the circuit after
performing a proper check, it needs to perform a leakage calibration to confirm the monitor
function is working properly.
Please note the initial leakage impedance will be different depending on the amplifiers
and speakers the IDA8 processors have connected.
How to perform a Leakage Calibration:
1. First, to get the correct leakage value (empty load), all the cables connected to the amplifiers
and the speaker lines on IDA8 need to be removed. After disconnected the cables, if the
range of leakage impedance is 8.xx~9.xx M ohm during the empty load, please continue to
go to Step 2.
If the range of leakage impedance is smaller than/equal as 8.xxM ohm, this indicates as
a hardware problem, please replace a new IDA8.
2. Click the Leakage Calibration button to proceed this action. After the calibration, the leakage
impedance value will go to 10Mohm.
3. For testing whether the leakage monitoring is working properly, users can try to connect
either speaker +/- pin shorted to ground or AMP-O +/- pin shorted to ground, the leakage
values should be 0.00 ohm, this is for triggering a leakage fault for testing.
4. If the leakage values are not 0, this will indicate as a hardware problem, please replace a new
IDA8.
Global Enable Monitor:
If users want to enable the monitoring function on all the connected IDA8 processors, you
need to click the [Global Enable Monitor] option first, and change the [Enable Monitor]
option either by clicking to enable this function or unclick to cancel the monitoring function.
Global Enable Leakage:
If users want to enable the monitoring function on all the connected IDA8 processors, you
need to click the [Global Enable Leakage] option first, and change the [Enable Leakage]
option either by clicking to enable this function or unclick to cancel the monitoring function.
Global Leakage Threshold:
If users want to enable the monitoring function on all the connected IDA8 processors, you
need to click the [Global Leakage Threshold] option first, and change the [Leakage
Threshold 1k ohm] option either by clicking to enable this function or unclick to cancel the
