Parameters
Event Name: The name of the events that are
linked.
Content: A [...] link button to open the event
setting window to assign which elements to
control.
Logic Out: Define the state of output signal.
There are two cases which need to be
considered whether the event is proceeded
successfully or not. To finish this configuration,
first, you need to select the output signal what is
function/working, see the picture on the right.
Control Type:
o Value: Control the elements based on the
binary codes.
o Percentage: Control the elements based on
the relative percentage.
From the picture above, the logic output of
channel 1~3 are selected. Click the [...] grid
to open [Event Trigger] window.
The Value Control/Value Trigger/Step
Trigger/Step Control/Master Preset
Change/Sub-Present Change can be
modified by Event Value Control
component only.
