Ateis IDA8S User Manual

DSP Components 411
© 2020, ATEÏS. All rights reserved.
Control Window
Elements
Priority: The priority depends on the list order.
Message Name: Click [...] to manage the messages stored in the device or PC.
Mode: Choose the mode of playing messages.
Control: Control by the Logic signal. The signal will be high when the message is playing, and
will stop if it is low.
Trigger: Play the message in "1 + the Times you set". For example, it will play 5 times if you
set 4 at the last column.
Times: Set for trigger.
Control Window
You can set the Message play list from the setting window as below.
Elements
Mode:
o Logic Input: Choose Logic IN1~ IN8 to control the message play, If you set more than one
messages on the same Logic input. it will play those messages in order.
o Dynamic: Use dynamic to manage the messages. Choose Dynamic and click [...] to open
[Dynamic assembling message setting] window. See the picture below.
