DSP Components 427
© 2020, ATEÏS. All rights reserved.
Network Cascading Paging
Some applications like PA station system requires a huge number of zones for paging by
connecting to multiple Ateis audio processors via Ateis Net. The Network Paging configuration
of every audio processor will be in charge of the paging tasks. See the example as below,
Double click the Network Paging component to open the settings window, the following
sections will describe the parameters of each tab.
The Network Paging component will occupied with 2 x message channels, please refer to
Message Limitation chapter.
Source List
A source list allows to assign the paging source (from 1 to 16 channel). If a zone is under the paging
status, the zone needs to know which paging source comes from.
