Ateis IDA8S User Manual

IDA8 Global-Net User Manual504
© 2020, ATEÏS. All rights reserved.
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
0.04
%
20~20kHz@+4dBu
-12dBu
-
0.06
%
20~20kHz@-2dBu
-24dBu
-
0.06
%
20~20kHz@-14dBu
-40dBu
-
0.06
%
20~20kHz@-30dBu
-54dBu
-
0.06
%
20~20kHz@-44dBu
EIN (Equivalent Input Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
-81
dBu
20~20kHz@150Ω
-12dBu
-
-93
dBu
20~20kHz@150Ω
-24dBu
-
-104
dBu
20~20kHz@150Ω
-40dBu
-
-112
dBu
20~20kHz@150Ω
-54dBu
-
-115
dBu
20~20kHz@150Ω
Configurable Audio Output
Maximum level = 14 dB
Output Impedance = 50 Ohm
Bandwidth =±1dB@ 20Hz ~ 20kHz
THD+N (Total Harmonic Distortion plus Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
0.04
%
20~20kHz@+4dBu
-12dBu
-
0.06
%
20~20kHz@-2dBu
-24dBu
-
0.06
%
20~20kHz@-14dBu
-40dBu
-
0.06
%
20~20kHz@-30dBu
-54dBu
-
0.06
%
20~20kHz@-44dBu
EIN (Equivalent Input Noise)
Sensitivity
Minimum
Maximum
Unit
Frequency
0dBu
-
-81
dBu
20~20kHz@150Ω
-12dBu
-
-93
dBu
20~20kHz@150Ω
-24dBu
-
-104
dBu
20~20kHz@150Ω
-40dBu
-
-112
dBu
20~20kHz@150Ω
-54dBu
-
-115
dBu
20~20kHz@150Ω
Speaker Line/Amplifier, Monitor Speaker
Speaker line/Amplifier
Monitoring Speaker
Maximum Power: 800W(RMS)
Impedance: 8 Ohm
Maximum Power (Siren + Message):
1000W
Maximum Power @ 1kHz: 1.6W
THD @ 1kHz = < 1%
Bandwidth @ -3dB = 100Hz ~ 12kHz
Configurable Audio Input
Sensitivity
For each channel of a configurable audio input card, there are five levels to gain the audio
signal. They are sensitivity values of 0dBu, -12dbBu, -24dBu, -40dBu and -54dBu
respectively. The meaning of sensitivity value is how large the gain is for an audio source,
and to amplify the giving minus input source to 0dBu. The figure below is an example of
when the sensitivity value is set to -54dBu, and input source is -54dBu, after the gaining
circuit of the audio card you'll get the 0dBu of output.
