Technical Data 517
© 2020, ATEÏS. All rights reserved.
The following batteries have been approved:
o Fiamm FG Series
o Yuasa NP Series
o Effekta BTL Series
o Powersonic GB Series
o Long GB Series
o Sun FT Series
o Enersys VE Series
o ABT TM Series
Note: If you would like to use another battery type, please let us approve them.
Environmental Specifications:
o Operating temperature: -5 °C to +45 °C at 12 A.
o Altitude : The max operating temperature decreases of 5°C every 1000 m when over
2000m.
o Storage temperature: -25 to +85 °C.
o Operating relative humidity: 20 to 95 % without condensation,
o Storage relative humidity: 100 to 95 %.
Summary of Available Equipment
Battery Test:
o The battery presence test is performed in the following manner: every 30 seconds for the
first 20 minutes after commissioning and every 15 minutes after. As soon as a fault is
detected, the test is performed every 30 seconds until 20 minutes after the fault
disappears.
o The impedance measurement test occurs every 4 hours if the mains is present on the
power supply and if his current is < 12A. The impedance limit value is 13 mW ±10 % in
24V and 26 mW ±10% in 48V.
Temperature Compensation:
A battery voltage compensation system maintains the charge characteristics within the
limits specified by the battery manufacturer across the entire operational temperature range.
Battery Low Voltage Protection:
o The battery low voltage protection threshold is 21,6 V ±3 % (SON 24V 12A MS150 RACK)
or 43.2 V ±3 % (SON 48V 12A MS150 RACK).
o The element causing the cut-out will be in the + position.
Battery Reverse Connection Protection:
o At start-up: the battery relays will not close.
o During operation: the fuse F8 will blow out.
Maintenance:
In order to ensure maximal and durable service, we strongly recommend that your product
must be maintained clean and ensure that it is installed in a dry and ventilated location. We
shall in no case be liable for damages associated with improper use or incorrect
maintenance of the equipment.
