Barco FLM series User Manual

3. Troubleshooting
Error 1694 : “Green form. start failed”
Situation Solution
No communication with the
formatter board of the green
channel. The projector fails to start.
• Check if both wire units between the Formatter Interface Board (FIB) and the
formatter board of the green channel are plugged in properly.
• Check if none of the wires came loose from the plugs on the wire unit.
• Reboot the projector. If the problem remains contact Barco for further instructions.
The formatter board of the green channel is malfunctioning and has to be replaced
at the factory.
Error 1695 : “Red form. start failed”
Situation Solution
No communication with the
formatter board of the red channel.
The projector fails to start.
• Check if both wire units between the Formatter Interface Board (FIB) and the
formatter board of the red channel are plugged in properly.
• Check if none of the wires came loose from the plugs on the wire unit.
• Reboot the projector. If the problem remains contact Barco for further instructions.
The formatter board of the red channel is malfunctioning and has to be replaced
at the factory.
Error 1696 : “Formatter ctrl init failed”
Situation Solution
The Formatter Interface Board
failed to initialize. The orange LED
“PWRGood” lights up. The green
status LED “FPGA DONE” on the
Formatter Interface Board remains
off (image 3-3 & image 3-4).
• Try to reload the flash software of the Formatter Interface Board.
• Check if the Formatter Interface Board is inserted well.
• If the problem remains replace the Formatter Interface Board.
The local power supplies on the
Formatter Interface Board fails. The
orange LED “PWRGood” remains
off (image 3-3 & image 3-4).
Replace the Formatter Interface Board.
The Formatter Interface Board has
no power. All status LED’s on the
Formatter Interface Board remains
off while the status LED “+5V FIB”
(image 3-6) on the Fan & Motor
Control Board lights up.
To see the status LED’s of the Fan
& Motor Control Board you have to
remove the projector input cover.
Replace the Formatter Interface Board.
The Formatter Interface Board has
no power. All status LED’s on the
Formatter Interface Board remains
off and the status LED “+5V FIB”
(image 3-6)on the Fan & Motor
Control Board remains off as well.
To see the status LED’s of the Fan
& Motor Control Board you have to
remove the projector input cover.
• Check if the Formatter Interface Board is well inserted.
• Replace the Fan & Motor Control Board.
R59770072 FLM SERIES 19/03/2007 19
