Barco FLM series

28. Start pulse generator
-
+
Image 28-10
Warning: Make sure that both SPG cables are provided with ferrite blocks (C). Reuse the ferrite blocks of the removed SPG
module in case no ferrite blocks are present upon the installed SPG module.
C
C
Image 28-11
5. Reinstall the lamp house and the covers of the projector.
R59770072 FLM SERIES 19/03/2007
311
