Belarus 892 - Tow Hitch TSU-1 ZH (Crossbar); Tow Hitch TSU-1 ZH-01 (Twin Crossbar)

892-0000010B OM
143
3.13.7 Tow hitch TSU-1ZH (crossbar)
Figure 3.13.5 – Installation scheme of TSU-1ZH
Table 3.13.3 – Basic parameters and coupling dimensions of TSU-1ZH (crossbar)
Standard size
(
confi
g
uration
)
TSU-1ZH
(
crossbar
)
1 Mountin
g
location On front ends of detachable lower links
2 Purpose For connection and coupling of trailed and
semi-trailed agricultural machines, equipped
with cou
p
lin
g
e
y
es.
3 Distance between PTO shaft end and connection
pin axis, mm
400
4 Diameter of crossba
r
holes for connecting pin,
mm
32
5 Vertical load on tow hitch in coupling point, kN,
not more than
6,5
6 Kin
g
p
in diameter, mm 30
7 Protective mean t
yp
e Safet
y
chain
(
ro
p
e
)
1)
8 Connection point of a protective mean on the trac-
to
r
Free holes of crossbar (not used for
y
oke fastenin
g)
1)
Im
p
lement accessor
y
.
3.13.8 Tow hitch TSU-1ZH-01 (twin crossbar)
Figure 3.13.6 – Installation scheme of TSU-1ZH-01
Table 3.13.4 – Basic parameters and coupling dimensions of TSU-1ZH-01 (twin crossbar)
Standard size
(
confi
g
uration
)
DH-1ZH-01
(
twin crossbar
)
1 Mountin
g
location On rear ends of telesco
p
ic lower links
2 Purpose For connection and coupling of trailed and
semi-trailed agricultural machines, equipped
with cou
p
lin
g
e
y
es.
3 Distance between PTO shaft end and connection
pin axis, mm
320, 400, 480
–
for tractors with hydrau-
lic lift
390, 470, 550 – for tractors with draft
control unit
4 Diameter of crossba
r
holes for connecting pin,
mm
32,5
5 Vertical load on tow hitch in coupling point, kN,
not more than
12
6 Kin
g
p
in diameter, mm 30
7 Protective mean t
yp
e Safet
y
chain
(
ro
p
e
)
1)
8 Connection point of a protective mean on the trac-
to
r
Free holes of twin crossba
r
(not used for
kin
gp
in
)
