Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 19 Configuring Quality of Service for PVC Bundles
ATM PVC Selection
Verifying and Monitoring ATM PVC Bundles
To verify and monitor QoS for ATM PVC bundles, enter any of the following commands in privileged
EXEC configuration mode:
Command Purpose
Step 1
Router(config)# interface atm
slot/module/port.subinterface
Creates or modifies a subinterface. Enters subinterface
configuration mode.
Step 2
Router(config-subif)# bundle bundle-name
Creates or modifies the PVC bundle. Enters ATM bundle
configuration mode.
bundle-name is the name of the bundle to which you want to
attach the VC class.
Step 3
Router(config-atm-vcb)# pvc-bundle
pvc_name [vpi/]{vci}
Adds the specified PVC to the bundle if it does not exist already.
Enters ATM bundle member configuration mode.
pvc-name is a name that you can use to refer to the PVC.
(Optional) vpi/ is the virtual path identifier (VPI). The slash is
required.
(Optional) vci is the virtual channel identifier.
Step 4
Router(config-atm-vcb-vc)# no bump
traffic
Configures the PVC not to accept any bumped traffic that would
otherwise be redirected to it.
Command Purpose
Router# debug atm bundle adjacency events
Displays information about ATM bundle adjacency change
events.
Router# debug atm bundle errors
Displays information about bundle errors.
Router# debug atm bundle events
Displays a record of bundle events.
Router# show atm bundle bundle-name
Displays the bundle attributes assigned to each PVC bundle
member and the current working status of the PVC bundle
members.
bundle-name is the name of the bundle whose member
information is displayed. This is the bundle name specified by the
bundle command when the bundle was created.
Router# show atm bundle bundle-name statistics
[detail]
Displays statistics or detailed statistics about the specified
VC
bundle.
bundle-name specifies the name of the bundle whose member
information is displayed. This is the bundle name specified by the
bundle command when the bundle was created.
(Optional) detail displays detailed statistics.
Router# show atm map
Displays a list of all configured ATM static maps to remote hosts
on an ATM network and on ATM bundle maps.
