Cisco 10000 Series User Manual

5-20
Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 5 Distributing Bandwidth Between Queues
Distribution of Remaining Bandwidth Using Ratio
Configuration Examples for Distribution of Remaining Bandwidth Using Ratio
This section provides the following configuration examples:
• Configuring Bandwidth-Remaining Ratios on Ethernet Subinterfaces: Example, page 5-21
• Configuring Bandwidth-Remaining Ratios on ATM Subinterfaces: Example, page 5-21
• Configuring Bandwidth-Remaining Ratios on Class Queues: Example, page 5-22
• Verifying Bandwidth Remaining Ratios: Example, page 5-22
Step 11
service-policy child-policy-name
Applies the child policy map you specify to the traffic class.
The router applies the QoS actions specified in the child
policy to the traffic class.
child-policy-name is the name of the child policy.
Note The service-policy command typically requires that
you specify the direction of the traffic using the
input or output keywords. However, when
applying a child policy to a parent policy, do not
specify traffic direction.
Step 12
exit
Exits policy-map class configuration mode.
Step 13
exit
Exits policy-map configuration mode.
Step 14
interface type slot/module/port.subinterface
[point-to-point | multipoint]
Creates or modifies the interface you specify. Enters
subinterface configuration mode.
type is the interface type (for example, Gigabit Ethernet).
slot/module/port.subinterface is the number of the
subinterface that identifies the subinterface (for example,
1/0/0.1).
(Optional) point-to-point indicates that the subinterface is
a point-to-point subinterface.
(Optional) multipoint indicates that the subinterface is a
point-to-multipoint subinterface.
Step 15
service-policy {input | output}
parent-policy-name
Applies the parent policy to the subinterface.
input indicates to apply the service policy to inbound
traffic.
output indicates to apply the service policy to outbound
traffic.
parent-policy-name is the name of the parent policy map.
Note When congestion occurs, the class queues receive
bandwidth according to the specified class-level
bandwidth-remaining ratios.
Command or Action Purpose
