13-27
Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 13 Defining QoS for Multiple Policy Levels
Verifying the Configuration of Hierarchical Policies
class precedence_2
shape average 500000
bandwidth remaining ratio 60 <---- Class-level ratio
!
policy-map vlan10_policy
class class-default
shape average 1000000
bandwidth remaining ratio 10 <---- Subinterface-level ratio
service-policy child-policy
!
policy-map vlan20_policy
class class-default
shape average 1000000
bandwidth remaining ratio 100 <---- Subinterface-level ratio
service-policy child_policy
!
!
interface GigabitEthernet 1/0/0.10
encapsulation dot1q 10
service-policy output vlan10_policy
!
interface GigabitEthernet 1/0/0.20
encapsulation dot1q 20
service-policy output vlan20_policy
For information on bandwidth-remaining ratios, see “Distribution of Remaining Bandwidth Using
Ratio” section on page 5-14 or the Distribution of Remaining Bandwidth Using Ratio,
Release 12.2(31)SB2 feature module.
Verifying the Configuration of Hierarchical Policies
To verify hierarchical policies, enter any of the following commands in privileged EXEC mode:
Command Purpose
Router# show class-map
Displays the configuration of all class maps configured on the
router.
Router# show policy-map
Displays the configuration of all policy maps configured on the
router.
Router# show policy-map interface
Displays the configuration of all classes configured for all policy
maps attached to all interfaces.
