Chapter 17 Configuring Dynamic Subscriber Services
Dynamically Changing VC Weight and Watermark Values
Verification Example for Dynamic VC Weights and Watermarks
Example 17-12 shows sample output for the show atm vc command, which enables you to display
information about a particular VC. As indicated in the example, the high watermark for VCD 2 is set to
240 and the low watermark is set to 224. The weight is set to 12.
Example 17-12 Sample Output for the show atm vc Command
Router# show atm vc 2
ATM7/0/0: VCD: 2, VPI: 1, VCI: 100
UBR, PeakRate: 599040 (1412831 cps)
CDVT: 178.5 Usecs, High Watermark: 240, Low Watermark: 224
AAL5-LLC/SNAP, etype:0x0, Flags: 0xC20, VCmode: 0x0, Encapsize: 12
Channel Weight: 12
OAM frequency: 0 second(s)
InARP frequency: 15 minutes(s)
High Watermark: 240, Low Watermark: 224
InPkts: 25, OutPkts: 26, InBytes: 626, OutBytes: 563
InPRoc: 26, OutPRoc: 26, Broadcasts: 0
InFast: 0, OutFast: 0
InPktDrops: 0, OutPktDrops: 0
Out CLP=1 Pkts: 0
OAM cells received: 0
OAM cells sent: 0
Status: UP
DBS enabled.
PPPoA Current State = LCP_NEGOTIATION
PPPoA Latest Event = PPP Msg
PPPoA Latest Error = None
PPPoA Session ID = 4
PPPoA Handle = 0xA8000003, SSS Handle = 0x00000000
Switch Handle = 0xF5000003, PPP Handle = 0x18000005
AAA Unique ID = 0x00000005, AIE Handle = 0xBE000003
Router# show atm vc [vcd | interface
interface-number]
Displays traffic information about all ATM permanent virtual
circuits (PVCs).
(Optional) vcd is a specific virtual circuit. When you specify a
VC, information displays about only that VC.
(Optional) interface interface-number is an interface or
subinterface number. When you specify an interface, information
displays about all of the PVCs configured on the specified
interface or subinterface.
Router# show atm pvc dbs
Displays all of the PVCs with dynamic bandwidth selection
(DBS) enabled and that have QoS parameters applied using
RADIUS.
Router# show atm pvc vpi/vci
Displays detailed information about an individual PVC.
vpi/ is the virtual path identifier. The slash is required.
vci is the virtual channel identifier.
Command Purpose
