Cisco 10000 Series User Manual

19-25
Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 19 Configuring Quality of Service for PVC Bundles
ATM PVC Selection
Configuring an ATM Bundle Member Using a VC Class
To configure an ATM bundle member using a VC class, perform the following configuration tasks:
• Configuring an ATM VC Class, page 19-25
• Attaching a VC Class to an ATM Bundle Member, page 19-27
Configuring an ATM VC Class
To configure an ATM VC class and specify the basis for ATM PVC selection, enter the following
commands beginning in global configuration mode:
Step 8
Router(config-atm-vcb-vc)# protect { group
| vc}
Configures the bundle member as part of the protected group of a
bundle or as an individually protected VC in a bundle.
group configures the VC or PVC bundle member as part of the
protected group of the bundle.
vc configures the VC or PVC member as individually protected.
Step 9
Router(config-atm-vcb-vc)# ubr [pcr]
(Optional) Configures unspecified bit rate (UBR) as the traffic
shaping rule for the VC.
(Optional) pcr is the peak cell rate (PCR).
Step 10
Router(config-atm-vcb-vc)# ubr+ pcr [mcr]
(Optional) Configures UBR plus (UBR+) as the traffic shaping
rule.
pcr is the peak cell rate (PCR)
(Optional) mcr is the minimum cell rate (MCR).
Step 11
Router(config-atm-vcb-vc)# vbr-nrt pcr
scr [mbs]
(Optional) Configures variable bit rate-nonreal-time (VBR-nrt) as
the traffic shaping rule.
pcr is the peak cell rate (PCR).
scr is the sustaining cell rate (SCR).
(Optional) mbs is the maximum burst size (MBS).
Command Purpose
Command Purpose
Step 1
Router(config)# vc-class atm name
Creates or modifies a VC class and enters VC class configuration
mode.
name is the name of the VC class.
Step 2
Router(config-vc-c)# oam-bundle [manage]
[frequency]
Enables end-to-end F5 Operation, Administration, and
Maintenance (OAM) loopback cell generation and OAM
management for a VC class that can be applied to a VC bundle.
(Optional) manage enables OAM management. If you omit this
keyword, loopback cells are sent, but the bundle is not managed.
(Optional) frequency is the number of seconds between
transmitted OAM loopback cells. Valid values are from 0 to 600
seconds. The default is 10 seconds.
