Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 19 Configuring Quality of Service for PVC Bundles
ATM PVC Selection
Adding an ATM PVC to a PVC Bundle
To add an ATM PVC to a PVC bundle, enter the following commands beginning in global configuration
mode:
Configuring ATM Bundle Members
You can configure PVC bundle members manually or by associating VC classes to the bundle members.
The parameter values that you configure manually for an individual PVC supersede the parameter values
applied to the ATM bundle. The parameter values that you configure manually for a PVC take
precedence over the parameters applied using a VC class.
To configure ATM bundle members, perform the following configuration tasks:
• Configuring an ATM Bundle Member, page 19-23
• Configuring an ATM Bundle Member Using a VC Class, page 19-25
• Configuring a PVC Not to Accept Bumped Traffic, page 19-27
Configuring an ATM Bundle Member
The parameter values that you configure manually for a PVC in ATM bundle member configuration
mode take precedence over the values of these parameters that you set for the PVC in any other
configuration mode, including a VC class applied in the ATM bundle member configuration mode.
To configure an ATM bundle member, enter the following commands beginning in global configuration
mode:
Command Purpose
Step 1
Router(config)# interface atm
slot/module/port.subinterface
Creates or modifies a subinterface. Enters subinterface
configuration mode.
Step 2
Router(config-subif)# bundle bundle-name
Creates or modifies the PVC bundle. Enters ATM bundle
configuration mode.
bundle-name is the name of the bundle to which you want to add
a PVC.
Step 3
Router(config-atm-vcb)# pvc-bundle
pvc_name [vpi/]{vci}
Adds the specified PVC to the bundle. Enters ATM bundle
member configuration mode.
pvc-name is a name that you can use to refer to the PVC.
Command Purpose
Step 1
Router(config)# interface atm
slot/module/port.subinterface
Creates or modifies a subinterface. Enters subinterface
configuration mode.
Step 2
Router(config-subif)# bundle bundle-name
Creates or modifies the PVC bundle and enters ATM bundle
configuration mode.
bundle-name is the name of the bundle.
