12-18
Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 12 Sharing Bandwidth Fairly During Congestion
Configuration Examples for Sharing Bandwidth Fairly
Deleting Policy Maps
To delete a policy map, enter the following command in global configuration mode:
Configuration Examples for Sharing Bandwidth Fairly
This section provides the following configuration examples:
• Configuration Example for Configuring CBWFQ and Attaching a Policy to an ATM Subinterface,
page 12-19
• Configuration Example for Configuring CBWFQ and Attaching a Policy to an RBE Subinterface,
page 12-19
Configuration Example for Configuring CBWFQ and Attaching a Policy to an
Ethernet Interface
Example 12-5 shows how to configure CBWFQ in a policy map and attach the policy to an Ethernet
interface. The example configures a classification policy named voip and a policy map named policy1,
which defines the class characteristics for the voip, video, and class-default classes. The service policy
is attached to the Ethernet 1/0/1 interface in the outbound direction.
Example 12-5 Configuring CBWFQ and Attaching a Policy to an Ethernet Interface
Router(config)# class-map match-any voip
Router(config-cmap)# match ip precedence 5
Router(config-cmap)# class-map match-any video
Router(config-cmap)# match ip precedence 4
Router(config-cmap)# exit
Router(config)# policy-map policy1
Router(config-pmap)# class voip
Router(config-pmap-c)# priority
Router(config-pmap-c)# police 560000
Router(config-pmap-c)# class video
Router(config-pmap-c)# bandwidth 4560
Router(config-pmap-c)# class class-default
Router(config-pmap-c) bandwidth 2560
Router(config-pmap-c)# exit
Router(config-pmap)# exit
Router(config)# interface ethernet1/0/1
Router(config-if)# service-policy output policy1
Router(config-if)# exit
Command Purpose
Router(config)# no policy-map policy-map-name
Deletes the policy map you specify.
policy-map-name is the name of the policy map.
