Chapter 16 Fragmenting and Interleaving Real-Time and Nonreal-Time Packets
Verifying and Monitoring Link Fragmentation and Interleaving
Verification Example for MLP Over Serial-Based LFI
Example 16-23 shows sample output from the show ppp multilink interface command. This example
displays information about the MLP over serial-based LFI configuration provided in Example 16-15 on
page 16-59.
Example 16-23 show ppp multilink interface Command Sample Output
Router# show ppp multilink interface Multilink2
Multilink2, bundle name is group2
Endpoint discriminator is group2
Bundle up for 02:31:57, 1/255 load
Receive buffer limit 36000 bytes, frag timeout 1000 ms
Bundle is Distributed
0/0 fragments/bytes in reassembly list
0 lost fragments, 0 reordered
0/0 discarded fragments/bytes, 0 lost received
0x0 received sequence, 0x1 sent sequence
C10K Multilink PPP info
Bundle transmit info
send_seq_num 0x1
Bundle reassembly info
expected_seq_num: 0x000000
Member links: 3 active, 0 inactive (max 10, min not set)
Se8/0/0.2/7:0, since 02:31:57, 384 weight, 378 frag size
Se8/0/0.2/9:0, since 00:03:46, 384 weight, 378 frag size
Se8/0/0.2/8:0, since 00:03:06, 384 weight, 378 frag size HQF2_R2#
Multilink2
Service-policy output: policy_MLPLFI
Class-map: prec_5 (match-all)
Router# show interfaces virtual-access number
[configuration]
Displays status, traffic data, and configuration information about
the virtual access interface you specify.
Note This command currently displays statistics for system
traffic only. Statistics for bundle traffic do not display.
For information about bundle traffic, see the show
interfaces or show ppp multilink command.
number is the number of the virtual access interface.
(Optional) configuration restricts output to configuration
information.
Router# show ppp multilink [bundle-interface]
Displays bundle information for all of the MLP bundles and their
PPP links configured on the router.
If you specify bundle-interface, the command displays
information for only that specific bundle.
(Optional) bundle-interface specifies the multilink interface (for
example, Multilink 5).
Router# show running-config
Displays information about the current router configuration,
including information about each interface configuration.
Command Purpose
