16-66
Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 16 Fragmenting and Interleaving Real-Time and Nonreal-Time Packets
Verifying and Monitoring Link Fragmentation and Interleaving
Router# show frame-relay fragment [interface
interface] [dlci]
(FRF.12 Fragmentation only) Displays information about Frame
Relay fragmentation such as fragmentation type, configured
fragment size, and the number of fragments transmitted, received,
and dropped. When you specify a specific interface and DLCI,
additional information appears.
For the PRE2, the show frame-relay fragment command
displays the number of output fragments.
interface is the type of interface for which you want to view
Frame Relay fragmentation information.
interface is the number of the interface containing the data-link
connection identifier (DLCI) for which you want to display
fragmentation information.
dlci is a specific number that identifies a DLCI on the interface.
If you do not specify any parameter options, the command
displays a summary of each DLCI configured for fragmentation.
Router# show frame-relay pvc [interface
interface] [dlci]
Displays statistics about PVCs for Frame Relay interfaces.
Note For MLP over Frame Relay-based LFI, this command
currently displays statistics for system traffic only. Data
statistics do not display.
interface is the type of interface for which you want to view
Frame Relay fragmentation information.
interface is the number of the interface containing the data-link
connection identifier (DLCI) for which you want to display
fragmentation information.
dlci is a specific number that identifies a DLCI on the interface.
Statistics for the specified PVC also display when you specify a
DLCI.
Router# show interfaces interface
Displays fragment and packet statistics for the interface you
specify.
interface is the type and number of the interface.
(FRF.12) For the PRE1, this command displays the number of
output fragments.
(FRF.12) For the PRE2 this command displays the number of
output packets. Output fragments display using the show
frame-relay fragment.
Interleaving data displays only if there are interleaves. For
example, the following line shows interleaves:
Output queue: 315/64/164974/31191
(size/threshold/drops/interleaves)
Command Purpose
