18-22

Cisco 10000 Series Router Quality of Service Configuration Guide

OL-7433-09

Chapter 18 Regulating and Shaping Subscriber Traffic

MQC Support for IP Sessions

Configuring QoS on Service Policy Maps With Traffic Classes

To configure QoS on service policy maps with traffic classes, enter the following commands beginning

in global configuration mode:

Step 3

Router(config-pmap-c)# police parameters

(Optional) Specifies the policing actions to implement on the

traffic.

parameters defines the way in which you want the traffic class to

be policed. For more information, see the police command in the

command reference documentation for Cisco IOS 12.2 SB.

Note Configure additional queuing and non-queuing actions as

required. For more information, see the

“Types of QoS

Actions” section on page 3-4.

Step 4

Router(config-pmap-c)# exit

Exits policy-map class configuration mode.

Step 1

Router(config-pmap)# policy-map type

service policy-map-name

Creates or modifies a service policy map, which is used to define

an Intelligent Service Gateway (ISG) subscriber service.

policy-map-name is the name of the service policy map.

Step 2

Router(config-pmap)# service-policy

{input | output} policy-map-name

Attaches the specified policy map to the service profile.

input indicates to apply the policy map to inbound traffic.

output indicates to apply the policy map to outbound traffic.

policy-map-name is the name of the policy map you specified in

Step 1.

Command Purpose

Step 1

Router(config)# policy-map

policy-map-name

Creates a policy map with the name you specify and enters

policy-map configuration mode.

policy-map-name is the name of the policy map.

Step 2

Router(config-pmap)# class class-map-name

Specifies the class of traffic to which the policy map applies.

class-map-name is the name of a previously configured class

map.
