Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 20 Configuring Quality of Service for MPLS Traffic
MPLS Traffic Engineering—DiffServ Aware
For more information about these commands, see the MPLS Traffic Engineering—DiffServ Aware,
Release 12.2(14)S feature module.
Configuration Examples for DS-TE
This section provides the following example configurations:
• Configuration Examples for Configuring the Tunnel Head Router, page 20-28
• Configuration Examples for Configuring DS-TE on the Midpoint Routers, page 20-30
• Configuration Examples for Configuring the Tail-End Router, page 20-31
• Configuration Examples for Configuring Guaranteed Bandwidth Service, page 20-31
Configuration Examples for Configuring the Tunnel Head Router
This section provides the following examples of how to activate DS-TE on the tunnel head router.
• Configuration Example for Configuring DS-TE on the Tunnel Head Router, page 20-29
• Configuration Example for Configuring DS-TE on the Tunnel Head Physical Interface, page 20-29
• Configuration Example for Configuring DS-TE on the Tunnel Interface, page 20-29
Router# show mpls traffic-eng link-management
bandwidth-allocation [interface name]
Displays current local link information.
(Optional) interface name indicates to display only those tunnels
that are admitted on the interface specified by name (for example,
serial 1/0/0).
Router# show mpls traffic-eng link-management
igp-neighbors [{igp-id {isis isis-address | ospf
ospf-id} | ip A.B.C.D}]
Displays Interior Gateway Protocol (IGP) neighbors.
Router# show mpls traffic-eng link-management
interfaces [interface]
Displays per-interface resource and configuration information.
(Optional) interface indicates to display information for the
specified interface.
Router# show mpls traffic-eng link-management
summary [interface name]
Displays summary of link management information.
(Optional) interface name indicates to display information for
the specified interface.
Router# show mpls traffic-eng topology [{A.B.C.D
| igp-id {isis nsapaddr | ospf A.B.C.D}] [brief]
Displays the MPLS traffic engineering global topology as
currently known at this node.
You can specify the node by IP address (router identifier to
interface address), IGP router identifier (igp-id), router
identification (nsapaddr) if using IS-IS, and router identifier
(A.B.C.D) if using OSPF.
(Optional) brief indicates to display a brief form of the output
that provides a less detailed version of the topology.
Router# show mpls traffic-eng tunnels
Displays information about tunnels.
Command Purpose
