Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Configuring Device Security
Defining 802.1X
Cisco Small Business SFE/SGE Managed Switches Administration Guide 91
4
• Trap Frequency — Defines the time period by which traps are sent to the host.
The Trap Frequency (1-1000000) field can be defined only if multiple hosts are
disabled. The default is 10 seconds.
STEP 3 Modify the relevant fields.
STEP 4 Click Apply. The settings are defined, and the device is updated.
Defining Authenticated Hosts
The Authenticated Hosts Page contains a list of authenticated users.
STEP 1 Click Security Suite > 802.1X > Authenticated Hosts. The Authenticated Hosts
Page
opens:
Authenticated Hosts Page
The
Authenticated Hosts Page contains the following fields:
• User Name — Lists the supplicants that were authenticated, and are permitted
on each port.
• Port — Displays the port number.
• Session time — Displays the amount of time (in seconds) the supplicant was
logged on the port.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
