Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 206
7
• IP Address — The currently configured IP address.
• Network Mask — Displays the currently configured IP address mask.
• Prefix Length — Specifies the length of the IPv6 prefix. The range is 5 -128 (64
in the case EUI-64 parameter is used). The
Prefix field is applicable only when
the IPV6 Static IP Address is defined as a Global IPv6 Address.
• User Defined Default Gateway — Manually defined default gateway IP
address.
• Active Default Gateway — Active default gateway’s IP Address.
• Remove User Defined — Removes the selected IP address from the interface.
The possible field values are:
- Checked — Removes the IP address from the interface.
- Unchecked — Maintains the IP address assigned to the Interface.
STEP 2 Click Apply. The IP Interface settings are defined, and the device is updated.
Defining IPv4 Interface (Layer 3)
The IPv4 Interface Page contains fields for assigning IPv4 addresses. Packets are
forwarded to the default IP when frames are sent to a remote network. The
configured IP address must belong to the same IP address subnet of one of the IP
interfaces. This section is applicable to Layer 3 devices only.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
