Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Configuring Device Security
Defining Authentication
Cisco Small Business SFE/SGE Managed Switches Administration Guide 44
4
Click Apply. The local user settings are modified, and the device is updated.
Defining Authentication
The Authentication section contains the following pages:
• Defining Profiles
• Mapping Authentication Profiles
• Defining TACACS+
• Defining RADIUS
Defining Profiles
Authentication profiles allow network administrators to assign authentication
methods for user authentication. User authentication can be performed locally or
on an external server. User authentication occurs in the order the methods are
selected. If the first authentication method is not available, the next selected
method is used. For example, if the selected authentication methods are RADIUS
and Local, and the RADIUS server is not available, then the user is authenticated
locally.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
