Viewing Statistics
Configuring RMON History
Cisco Small Business SFE/SGE Managed Switches Administration Guide 375
17
Edit RMON History Page
The
Edit RMON History Page contains the following fields:
• History Entry No. — Displays the entry number for the History Control Table
page.
• Source Interface — Displays the interface (port or LAG) from which the history
samples are taken. The possible field values are:
- Port — Specifies the port from which the RMON information is taken.
- LAG — Specifies the LAG from which the RMON information is taken.
• Owner — Displays the RMON station or user that requested the RMON
information. The field range is 0-20 characters.
• Max No. of Samples to Keep — Indicates the number of samples to save.
• Sampling Interval — Indicates the time in seconds that samplings are taken
from the ports. The field range is 1-3600. The default is 1800 seconds (equal to
30 minutes).
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The history control settings are modified, and the device is updated.
Viewing the RMON History Table
The RMON History Table Page contains interface specific statistical network
samplings. Each table entry represents all counter values compiled during a single
sample.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
