Configuring Multicast Forwarding
Defining Multicast TV Membership
Cisco Small Business SFE/SGE Managed Switches Administration Guide 243
9
Multicast Group — Indicates the Multicast group IP address for which the IGMP
Snooping is enabled.
STEP 2 Click the Add button. The
Add IGMP Snooping Mapping Page
opens:
Add IGMP Snooping Mapping Page
The
Add IGMP Snooping Mapping Page
contains the following fields:
VLAN — Defines the Multicast TV VLAN on which to enable IGMP Snooping.
Multicast Group — Defines the Multicast group IP address on which to enable
IGMP Snooping.
STEP 3 Define the fields.
STEP 4 Click Apply. IGMP Snooping is enabled on the specified Multicast TV VLAN, and
the device is updated.
Defining Multicast TV Membership
The
Multicast TV Membership Page
allows network managers to display the ports
associated with a Multicast TV VLAN.
NOTE Ports and trunks are assigned to Multicast VLAN in the
VLAN Interface Setting Page
(Layer 2)
.
To view Multicast TV VLAN membership:

Table of Contents

Other manuals for Cisco SGE2000 - Cisco - Gigabit Switch

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco SGE2000 - Cisco - Gigabit Switch and is the answer not in the manual?

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General IconGeneral
Form FactorRack-mountable
Switching Capacity48 Gbps
Forwarding Rate35.7 Mpps
LayerLayer 2
Power SupplyInternal
ManagementWeb-based, SNMP, CLI
MAC Address Table Size8000 entries
VLANs256
FeaturesQuality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature0°C to 40°C (32°F to 104°F)
Storage Temperature-20 to 70°C (-4 to 158°F)
Relative Humidity10% to 90% non-condensing
Standards ComplianceIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
