Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 210
7
STEP 3 Click Apply. ARP Proxy is enabled, and the device is updated.
Defining UDP Relay (Layer 3)
The UDP Relay allows UDP packets to reach other networks. This feature enables
browsing from workstations to servers on different networks. This section is
applicable to Layer 3 devices only.
To define UDP Relay:
STEP 1 Click System > System Management > IP Addressing > UDP Relay. The Defining
UDP Relay Page
opens:
Defining UDP Relay Page
The
Defining UDP Relay Page contains the following fields:
• Source IP Interface — Indicates the input IP interface that relays UDP packets.
If this field is 255.255.255.255, UDP packets from all interfaces are relayed. The
following address ranges are
- 0.0.0.0 to 0.255.255.255.
- 127.0.0.0 to 127.255.255.255.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
