Configuring Quality of Service
Defining Advanced QoS Mode
Cisco Small Business SFE/SGE Managed Switches Administration Guide 297
11
• Ingress Committed Information Rate (CIR) — Defines the CIR in Kbps. This field
is only relevant when the Police value is Single.
• Ingress Committed Burst Size (CS) — Defines the CS in bytes. This field is only
relevant when the Police value is Single.
• Exceed Action — Action assigned to incoming packets exceeding the CIR. This
field is only relevant when the Police value is Single. Possible values are:
- Drop — Drops packets exceeding the defined CIR value.
- Out Of Profile DSCP —Remarks packet’s DSCP values exceeding the
defined CIR value.
- None —Forwards packets exceeding the defined CIR value.
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The device is updated.
Defining Policy Binding
In the Policy Binding Page , QoS policies are associated with specific interfaces.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
