Configuring VLANs
Defining VLAN Interface Settings
Cisco Small Business SFE/SGE Managed Switches Administration Guide 176
6
Defining VLAN Interface Settings
The VLAN Interface Setting Page provides parameters for managing ports that are
part of a VLAN. The port default VLAN ID (PVID) is configured on the VLAN
Port
Settings
page. All untagged packets arriving to the device are tagged by the ports
PVID.
The varies, depending on whether the device is in Layer 2 or Layer 3 mode
(definable on the device through the CLI interface).
Layer 2 devices support Multicast TV VLAN, which can be enabled for individual
ports on the
Edit VLAN Ports Page .
STEP 1 Click Bridging > VLAN Management > Interface Settings. The VLAN Interface
Setting Page
opens:
VLAN Interface Setting Page
The
VLAN Interface Setting Page contains the following fields:
• Copy From Entry Number — Copies VLAN configuration from the specified
table entry.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
