Configuring Device Security
Defining Access Control
Cisco Small Business SFE/SGE Managed Switches Administration Guide 100
4
Defining IP Based ACL
The IP Based ACL Page page contains information for defining IP Based ACLs,
including defining the ACEs defined for IP Based ACLs.
To define an IP based ACL:
STEP 1 Click Security Suite >Access Control > IP Based ACL. The IP Based ACL Page
opens:
IP Based ACL Page
The
IP Based ACL Page contains the following fields:
• ACL Name — Displays the user-defined IP based ACLs.
• Rule Priority — Indicates the rule priority, which determines which rule is
matched to a packet on a first-match basis.
• Protocol — Creates an ACE based on a specific protocol. The possible field
values are:
- ICMP — Internet Control Message Protoco l (ICMP). The ICMP allows the
gateway or destination host to communicate with the source host. For
example, to report a processing error.
- IGMP — Internet Group Management Protocol (IGMP). Allows hosts to
notify their local switch or router that they want to receive transmissions
assigned to a specific multicast group.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
