Managing System Files
Save Configuration
Cisco Small Business SFE/SGE Managed Switches Administration Guide 331
13
• Supported IP Format — Indicates the supported IP version. The possible
values are:
- — Indicates the device supports IPv6.
- — Indicates the device supports IPv4.
• IPv6 Address Type — Displays the IPv6 Type. The possible field values are:
- Link local — Indicates the IPv6 address is link-local, that uniquely
identifies hosts on a single network
link. A Link-local address has a prefix of
‘FE80’. The link-local addresses are not routable and can be used for communication on
the same network only.
- Global — Indicates the IPv6 address is a global Unicast IPV6 type which
is visible and reachable from different subnets.
• VLAN the VLAN is defined as the Link Local Interface.TFTP Server —
Specifies the TFTP Server IP Address from which files are downloaded.
• Source File — Specifies the file to be downloaded. This field is applicable for
upgrades only.
• Destination File — Specifies the name of the file after it is downloaded (Save
As).
• Download to Master Only — Downloads the file to the Stacking Master only.
• Download to all Units — Downloads the file to all stacking members.
STEP 2 Define the relevant fields.
STEP 3 Click Apply. The device is updated.
Save Configuration
The configuration files control the operation of the switch, and contain the
functional settings at the device and the port level. Configuration files are one of
the following types:
• Factory Default — Contains preset default parameter definitions which are
downloaded with a new or upgraded version.
• Running Configuration — Contains the parameter definitions currently defined
on the device. This includes any configuration changes made since the device
