Viewing Statistics
Configuring RMON History
Cisco Small Business SFE/SGE Managed Switches Administration Guide 377
17
• Received Packets — Displays the number of packets received on the interface
since the page was last refreshed, including bad packets, Multicast and
Broadcast packets.
• Broadcast Packets — Displays the number of good Broadcast packets
received on the interface since the page was last refreshed. This number does
not include Multicast packets.
• Multicast Packets — Displays the number of good Multicast packets received
on the interface since the page was last refreshed.
• CRC Align Errors — Displays the number of CRC and Align errors that have
occurred on the interface since the page was last refreshed.
• Undersize Packets — Displays the number of undersized packets (less than 64
octets) received on the interface since the page was last refreshed.
• Oversize Packets — Displays the number of oversized packets (over 1518
octets) received on the interface since the page was last refreshed.
• Fragments — Displays the number of fragments (packets with less than 64
octets, excluding framing bits, but including FCS octets) received on the
interface since the page was last refreshed.
• Jabbers — Displays the total number of received packets that were longer
than 1518 octets. This number excludes frame bits, but includes FCS octets
that had either a bad Frame Check Sequence (FCS) with an integral number of
octets (FCS Error) or a bad FCS with a non-integral octet (Alignment Error)
number. The field range to detect jabbers is between 20 ms and 150 ms.
• Collisions — Displays the number of collisions received on the interface since
the page was last refreshed.
• Utilization — Displays the percentage of the interface utilized.
STEP 3 To return to the
RMON History Control Page
, click the Interface Table button.
Defining RMON Events Control
The
RMON Events Page
contains fields for defining RMON events.
To view RMON events:
