Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Getting Started
Using Screen and Table Options
Cisco Small Business SFE/SGE Managed Switches Administration Guide 6
1
Add SNTP Server Page
STEP 3 Define the fields.
STEP 4 Click Apply. The configuration information is saved, and the device is updated.
Modifying Device Information
STEP 1 Open the interface page.
STEP 2 Select a table entry.
STEP 3 Click the Edit Button. A Modify page opens, for example, the Edit RMON Events
Page
opens:
Edit RMON Events Page
STEP 4 Define the fields.
STEP 5 Click Apply. The fields are modified, and the information is saved to the device.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
