Configuring Device Security
Defining Access Control
Cisco Small Business SFE/SGE Managed Switches Administration Guide 121
4
STEP 3 Define the relevant fields,
STEP 4 Click Apply. The IP Based ACL is modified, and the device is updated.
Defining ACL Binding
When an ACL is bound to an interface, all the ACE rules that have been defined are
applied to the selected interface.
Whenever an ACL is assigned on a port or a LAG
flows from that ingress interface that do not match the ACL are matched to the
default rule, which is Drop unmatched packets. To bind ACLs to an interface:
STEP 1 Click Security Suite > Access Control > ACL Binding. The ACL Binding Page
opens:
ACL Binding Page
The
ACL Binding Page contains the following fields:
• Copy From Entry Number — Copies the ACL binding configuration from the
specified table entry.
• To Entry Number(s) — Assigns the copied ACL binding configuration to the
specified table entry.
• Ports /LAGs — Indicates the interface to which the ACL is bound.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
